Front side member tooling hole (Ø12)
Fender apron upper member tooling
hole (Ø7)
Front door upper hinge mounting hole
(Ø13)
Front door lower hinge mounting
hole (Ø13)
Rear door upper hinge mounting hole
(Ø13)
Rear door lower hinge mounting hole
(Ø13)
Rear door switch mounting hole (Ø10)
Quarter fixed garnish mounting hole
(Ø7)
Side outer panel rear corner
Rear bumper mounting hole (8.5X8.5)
