Curtain airbag mounting hole (Ø6.6) | Curtain airbag mounting hole (Ø6.6) | Cowl crossbar mounting hole (Ø9) |
 |  |  |
Front door checker mounting hole (Ø13) | Cowl side trim mounting hole (Ø8.5) | Seat belt height adjuster upper mounting hole (Ø16) |
 |  |  |
Seat belt height adjuster lower mounting hole (Ø16) | Rear door checker mounting hole (Ø13) | Seat belt retractor mounting hole (Ø12) |
| | |
Seat belt height adjuster upper mounting hole (Ø16) | Seat belt height adjuster lower mounting hole (Ø16) | Rear door checker mounting hole (Ø13) |
|  |  |
Seat belt retractor mounting hole (Ø12) | Quarter inner upper panel tooling hole (Ø6.6) | Rear door striker mounting hole (Ø13) |
 |  |  |
Quarter inner lower panel tooling hole (Ø16) | Quarter inner lower panel tooling hole (Ø8.5) | Rear package tray panel tooling hole (Ø10.5) |
| | |
Curtain airbag mounting hole (Ø6.6) | Curtain airbag mounting hole (Ø6.6) | Cowl crossbar mounting hole (Ø9) |
| | |
Cowl side trim mounting hole (Ø8.5) | Seat belt height adjuster upper mounting hole (Ø16) | Seat belt height adjuster lower mounting hole (Ø16) |
|  | |
Seat belt retractor mounting hole (Ø12) | Front seat mounting hole (Ø11) |
| | |
Seat belt height adjuster upper mounting hole (Ø16) | Seat belt height adjuster lower mounting hole (Ø16) | Seat belt retractor mounting hole (Ø12) |
| | |
Quarter inner upper panel tooling hole (Ø6.6) | Quarter inner lower panel tooling hole (Ø16) | Quarter inner lower panel tooling hole (Ø8.5) |
|  | |
Rear package tray panel tooling hole (Ø10.5) | Rear floor panel tooling hole (Ø7) |
