Front pillar trim mounting hole (Ø8.5) | Front pillar trim mounting hole (Ø8) | Cowl cross bar mounting hole (Ø15) |
 |  |  |
Cowl side trim mounting hole (Ø8.5) | Front door checker mounting hole (Ø13) | Seatbelt height adjust upper mounting hole (Ø15) |
 |  | |
Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
| | |
Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
 |  |  |
Rear door checker mounting hole (Ø13) | Quarter inner panel tooling hole (Ø8.5) | Quarter inner panel tooling hole (Ø18) |
 |  | |
Wheel house inner trim mounting hole (Ø10) | Rear door striker mounting hole (Ø13) |
| | |
Front pillar trim mounting hole (Ø8.5) | Front pillar trim mounting hole (Ø8) | Cowl cross bar mounting hole (Ø15) |
| | |
Cowl side trim mounting hole (Ø8.5) | Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) |
|  | |
Front seatbelt retractor mounting hole (Ø12) | Front seat mounting hole (Ø13) |
| | |
Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
| | |
Quarter inner panel tooling hole (Ø8.5) | Quarter inner panel tooling hole (Ø18) | Wheel house panel tooling hole (Ø10) |
 | ||
Rear floor panel tooling hole (Ø7) |
| | |
Front pillar trim mounting hole (Ø8.5) | Front pillar trim mounting hole (Ø8) | Cowl cross bar mounting hole (Ø15) |
| | |
Cowl side trim mounting hole (Ø6.6) | Front door checker mounting hole (Ø13) | Seatbelt height adjust upper mounting hole (Ø15) |
| | |
Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
| | |
Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
|  |  |
Rear door checker mounting hole (Ø13) | Quarter inner trim mounting hole (Ø8.5) | Quarter inner panel tooling hole (Ø6.6) |
 |  |  |
Rear door striker mounting hole (Ø13) | Wheel house inner panel tooling hole (Ø6.6) | Rear pillar trim mounting hole (Ø8.5) |
 |  | |
Rear pillar trim mounting hole (Ø8.5) | Rear transverse trim mounting hole (Ø8.5) |
| | |
Front pillar trim mounting hole (Ø8.5) | Front pillar trim mounting hole (Ø8) | Cowl cross bar mounting hole (Ø15) |
| | |
Cowl side trim mounting hole (Ø6.6) | Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) |
| | |
Front seatbelt retractor mounting hole (Ø12) | Front seat mounting hole (Ø13) |
| | |
Seatbelt height adjust upper mounting hole (Ø15) | Seatbelt height adjust lower mounting hole (Ø15) | Front seatbelt retractor mounting hole (Ø12) |
| | |
Quarter inner trim mounting hole (Ø8.5) | Quarter inner panel tooling hole (Ø6.6) | Wheel house inner panel tooling hole (Ø6.6) |
| | |
Rear pillar trim mounting hole (Ø8.5) | Rear pillar trim mounting hole (Ø8.5) | Rear transverse trim mounting hole (Ø8.5) |
 | ||
Rear floor panel tooling hole (Ø7) |
