DTC NO | DIAGNOSTIC ITEM | |
P0755 | SHIFT CONTROL SOLENOID VALVE B | - Open -, - Short circuit - |
Controls fluid pressure that is acting on the shift control valve (SCV) through ON/OFF signals from the PCM to control shifting.
If resistance value of SCSV-B is too high or low, P0755 is output. (open or short circuit).
Detection condition | Possible cause | Check item |
● IG S/W "ON" or start release ● PCM senses an open/short in the SCSV-B | ● Malfunction of SCSV-B ● Malfunction of connector ● Malfunction of PCM | ● Open/short in SCSV-B circuit ● Malfunction of SCSV-B |
SYMPTOM ● Automatic transaxle will hold 3rd gear when code P0755 is generated. |
