3.
Erase the DTC with GDS.
Connect GDS to Data Link Connector(DLC).
Engine "ON" and Head lamp"ON".
Erase the DTC with GDS.
Is it possible to erase the DTC with GDS ?
 | ▶ This is a intermittent problem caused by poor contact of component or Control Unit. ▶ Thoroughly check the looseness, poor connection, bent, corrison, contamination, deformation or damage of connector. ▶ Repair or replace as necessary and then, go to "Verification of Vehicle Repair" procedure. |
 | ▶ Go to "Inspection and Repair" procedure. |
