Component Location
General Description

The steering angle sensor has a function to sense a steering angle and a velocity of a steering wheel.

The procedure is as follows : A drive turns a steering wheel → Main/Sub-gear turns → Rotation angle senses → A steering angle is calculated. The EPS(MDPS=Motor Driving Power Steering) CM uses signals of steering angle sensor and controls for its restoring and damping control.

DTC Description

If the signal of main/sub sensor is out of a normal range, the EPS (MDPS=Motor Driving Power Steering)CM sets DTC C1290.

DTC Detecting Condition

Item

Detecting Condition

Possible cause

DTC Strategy

•

Check Torque sensor signal

1.

Poor connection in Torque

sensor

2.

Torque sensor

Enable conditions

•

IG ON

Threshold value

•

If the signal of main/sub sensor is out of a normal range

Fail Safe

•

Motor : ON

•

Relay : ON
