6.
Monitor the parameters of 4 active WE sensors data.
1)
Specification : the parameters related to 4 active WE sensors are displayed normally.
Fig.1) Sensor current data (normal)
Park the vehicle on a level surface.
Set up ＇GDS＇ with ＇GDS TPMS＇.
Drive vehicle at a steady speed for more than 1 minute.
Select the "CURRENT DATA" function of "TPMS" system.
Select the "FULL" mode of "CURRENT DATA" function.
Monitor the parameters of 4 active WE sensors data.
Specification : the parameters related to 4 active WE sensors are displayed normally.
Fig.1) Sensor current data (normal)
Are the parameters normal?
▶ Fault is intermittent. It has been repaired and TPMS receiver module memory is not cleared yet.
▶ Go to "Verification of vehicle Repair" procedure.
▶ Substitute with a known-good TPMS receiver module and check for proper operation.
▶ If the problem is corrected, replace TPMS receiver module and then go to "Verification of Vehicle Repair" procedure.
