6.
Monitor the parameter of ＇Battery Positive Voltage＇on the screen.
1)
Specification : ＇Battery Positive Voltage＇is less than 16 V
Fig 1) Current data (normal)
Start engine and turn headlight and rear defroster on.
Set up ＇GDS＇ with ＇GDS TPMS＇.
Select the vehicle model and "TPMS" system.
Select "CURRENT DATA" function.
Maintaining ENG. RPM at 2,500RPM(idle) over 2 minutes.
Monitor the parameter of ＇Battery Positive Voltage＇on the screen.
Specification : ＇Battery Positive Voltage＇is less than 16 V
Fig 1) Current data (normal)
Is parameter within specifications?
▶ Fault is intermittent. It has been repaired and TPMS receiver module memory is not cleared yet.
▶ Go to "Verification of vehicle Repair" procedure.
▶ Go to "Inspection/Repair" procedure
