Curtain airbag mounting hole (Ø6.6) | Front pillar trim mounting hole (Ø8.5) | Cowl crossbar mounting hole (Ø9) |
 |  |  |
Front door checker mounting hole (Ø13) | Cowl side trim mounting hole (Ø6.6) | Curtain airbag mounting hole (Ø6.6) |
 |  |  |
Seat belt height adjust upper mounting hole (Ø16) | Seat belt height adjust lower mounting hole (Ø16) | Seat belt retractor mounting hole (Ø12) |
 |  |  |
Rear door checker mounting hole (Ø13) | Roof side inner rail tooling hole (Ø9) | Curtain airbag mounting hole (Ø6.6) |
 |  |  |
Curtain airbag mounting hole (Ø6.6) | Wheel house trim mounting hole (Ø8.5) | Rear door striker mounting hole (Ø13) |
 |  |  |
Rear seatbelt retractor bracket mounting hole (Ø16) | Rear pillar trim mounting hole (Ø8.5) | Luggage side trim mounting hole (Ø6.6) |
 |  |  |
Luggage side trim mounting hole (Ø7) | Floor wiring harness mounting hole (12X7) | Floor wiring harness mounting hole (12X7) |
 |  |  |
Floor wiring harness mounting hole (12X7) | Rear seat belt lower mounting hole (Ø16) | Rear floor panel tooling hole (8.5X8.5) |
 | ||
Front seat mounting hole (Ø13) |
