1

Ground

Chassis

2

ignition Coil #1 Control output

ECM C200-A (42)

3

-

4

Battery power (B+)

Main Relay

1

Ground

Chassis

2

ignition Coil #2 Control output

ECM C200-A (20)

3

-

4

Battery power (B+)

Main Relay

1

Ground

Chassis

2

ignition Coil #3 Control output

ECM C200-A (21)

3

-

4

Battery power (B+)

Main Relay

1

Ground

Chassis

2

ignition Coil #4 Control output

ECM C200-A (41)

3

-

4

Battery power (B+)

Main Relay
