World Manufacturer Identifier (WMI)

- KNA : Passenger vehicle, MPV(Multipurpose Passenger Vehicle)/SUV(Sports Utility Vehicle)/RV(Recreational Vehicle)

- KNC : Commercial vehicle (Van)

- KND : MPV/SUV/RV (For U.S.A, Canada, Mexico)

- KNH : Van

Vehicle line

- J : SOUL

Model ＆ Series

- M : Low grade (L)

- N : Middle-Low grade (GL)

- P : Middle grade (GLS, JSL, TAX)

- R : Middle-High grade (HGS)

Body/Cabin type, Gross Vehicle Weight Rating

KNA

- 1 : Limousine

- 2 : Sedan - 2 door

- 3 : Sedan - 3 door

- 4 : Sedan - 4 door

- 5 : Sedan - 5 door

- 6 : Coupe

- 7 : Convertible

- 8 : Wagon

- 9 : Commercial Van

- 0 : Pick-Up

KNC (Commercial vehicle / Van)

Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China

- X : Standard Cabin / Semi-Bonnet

- Y : Double Cabin / Bonnet

- Z : Super Cabin / Box

For U.S.A, Canada, Mexico, Gulf Cooperation Council, China

- 2 : Standard Cabin Class-H 4×2

- 3 : Standard Cabin Class-E 4×2 / Semi-Bonnet Class-E 4×2

- 4 : Standard Cabin Class-E 4×4 / Semi-Bonnet Class-E 4×4

- 5 : Standard Cabin Class-F 4×2 / Semi-Bonnet Class-F 4×2

- 6 : Standard Cabin Class-F 4×4 / Semi-Bonnet Class-F 4×4

- 7 : Double Cabin Class-E 4×2 / Bonnet Class-E 4×2

- 8 : Double Cabin Class-E 4×4 / Bonnet Class-E 4×4

- 9 : Double Cabin Class-F 4×2 / Bonnet Class-F 4×2

- 0 : Double Cabin Class-F 4×4 / Bonnet Class-F 4×4

- A : Super Cabin Class-E 4×2 / Box Class-E 4×2

- B : Super Cabin Class-E 4×4 / Box Class-E 4×4

- C : Super Cabin Class-F 4×2 / Box Class-F 4×2

- D : Super Cabin Class-F 4×4 / Box Class-F 4×4

KND

- 1 : Wagon 4×2 Class-A

- 2 : Wagon 4×2 Class-B

- 3 : Wagon 4×2 Class-C

- 4 : Wagon 4×2 Class-D

- 5 : Wagon 4×2 Class-E

- 6 : Wagon 4×2 Class-F

- 7 : Wagon 4×2 Class-G

- A : Wagon 4×4 Class-A

- B : Wagon 4×4 Class-B

- C : Wagon 4×4 Class-C

- D : Wagon 4×4 Class-D

- E : Wagon 4×4 Class-E

- F : Wagon 4×4 Class-F

- G : Wagon 4×4 Class-G

KNH

- 1 : Box

- 2 : Bonnet

- 3 : Semi-Bonnet

Restraint system, Brake system

KNA, KND

Except U.S.A, Canada, Mexico

- 0 : Both side - None

- 1 : Both side - Active belt

- 2 : Both side - Passive belt

For U.S.A, Canada, Mexico

KNC, KNH

Except U.S.A, Canada, Mexico

- 7 : Hydraulic brake system

- 8 : Pneumatic brake system

- 9 : Mixed brake system

For U.S.A, Canada, Mexico

- X : Hydraulic brake system

- Y : Pneumatic brake system

- Z : Mixed brake system

Engine type

-1 : Gasoline engine 1.6 MPI (Gamma)

-2 : Gasoline engine 1.6 GDI (Gamma)

-3 : Ethanol engine 1.6 FFV (Gamma)

-4 : Gasoline engine 2.0 MPI (Nu)

-6 : Diesel engine 1.6 TCI (U2)

Check digit or Driver’s side & Transmission

Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen

- A : LHD & MT

- B : LHD & AT

- C : LHD & MT+Transfer

- D : LHD & AT+Transfer

- E : LHD & CVT

- F : LHD & Decelerator

- G : LHD & DCT

- L : RHD & MT

- M : RHD & AT

- N : RHD & MT+Transfer

- S : RHD & AT+Transfer

- T : RHD & CVT

- U : RHD & Decelerator

- V : RHD & DCT

For U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen

- Check digit : 0 ~ 9, ×

Model year

- E : 2014, F : 2015, G : 2016, H : 2017 …

Plant of production

- 5 : Hwasung (Korea)

- 6 : Sohari (Korea)

- 7 : Kwangju (Korea)

- T : Seosan (Korea)

Vehicle production sequence number

- 000001 ~ 999999

Engine fuel

-G : Gasoline

-D : Diesel

Engine range

- 4 : 4 cycle 4 cylinder

Engine development order and capacity

- F : Gamma engine (Gasoline)

- N : Nu engine (Gasoline)

- F : U engine (Diesel)

Engine Capacity

- A : 1591cc (Gamma FFV)

-D : 1591cc (Gamma GDI)

- G : 1591cc (Gamma MPI)

- A : 1999cc (Nu MPI)

- B : 1582cc (U2)

Production year

- D : 2013, E : 2014, F : 2015, G : 2016 …

Plant of production

-A : Asan (Korea)

- B : Beijing (China)

- H : Hwasung (Korea)

- K : Montgomery (U.S.A)

- M : Chennai (India)

- P : Poseung (Korea)

- S : Sohari (Korea)

- T : Izmit (Turkey)

- U : Ulsan (Korea)

- W : Shandong (China)

- Z : Zilina (Slovakia)

- 1 : Yancheng (China)

Engine production sequence number

- 000001 ~ 999999

Model

- EA : A6MF1

Production year

Model year

- D : 2013, E : 2014, F : 2015, G : 2016....

Final gear ratio

- S : 3.320 (A6MF1)

Detailed classification

- F : U2 1.6

Plant of production

- 2 : HPT Plant 2

- 4 : HPT Plant 4

- U : Ulsan Plant 1

- S : Ulsan Plant 2

- N : Ulsan Plant 3

- A : PTA

- H : Hwasung

- C : PTC

Transaxle production sequence number

- 000001 ~ 999999

Model

- NA : A6GF1

- PA : A6MF1-1

Production yearModel year

- D : 2013, E : 2014, F : 2015, G : 2016....

Final gear ratio

- U : 3.957

- Q : 3.612

Detailed classification

- B : Gamma 1.6 MPI (A6GF1)

- E : Gamma 1.6 GDI (A6GF1)

- F : Gamma 1.6 GDI ISG (A6GF1)

- A : Nu 2.0 MPI (A6MF1-1)

Plant of production

- A : PTA

- C : PTC

- H : Hwasung

- U : Ulsan Plant 1

- S : Ulsan Plant 2

- 2 : HPT Plant 2

- 4 : HPT Plant 4

Transaxle production sequence number

- 000001 ~ 999999

Assembly code of plant

Model year

- D : 2013, E : 2014, F : 2015, G : 2016....

Plant of production

- B : Beijing (China)

- H : Hwasung (Korea)

- J : Ostrava (Chech)

- M : Chennai (India)

- U : Ulsan (Korea)

- W : Wia

Transaxle production sequence number

- 000001 ~ 999999

Model

- W : M6CF3-1

Model year

- D : 2013, E : 2014, F: 2015, G : 2016....

Plant of production

- B : Beijing (China)

- W : Hwasung (Korea)

- J : Ostrava (Chech)

- M : Chennai (India)

- U : Ulsan (Korea)

Speed

Spare

Final gear ratio

- L : 4.467 (NU 2.0 MPI)

- E : 4.188 (U2 1.6)

Transaxle production sequence number

- 000001 ~ 999999
