1

-

1

-

2

-

2

-

3

-

3

-

4

Passenger airbag on lamp

4

-

5

Passenger airbag off lamp (Telltale Lamp)

5

Side impect sensor [Passenger] High

6

-

6

Side impect sensor [Passenger] Low

7

Ignition

7

Side impact sensor [Driver] Low

8

Front impact sensor [Driver] High

8

Side impact sensor [Driver] High

9

Front impact sensor [Driver] Low

9

-

10

Front impact sensor [Passenger] Low

10

Ground

11

Front impact sensor [Passenger] High

11

-

12

-

12

Side airbag [Driver] High

13

-

13

Side airbag [Driver] Low

14

Passenger airbag ON/OFF switch low

14

Side airbag [Passenger] Low

15

Passenger airbag ON/OFF switch high

15

Side airbag [Passenger] High

16

-

16

-

17

-

17

-

18

-

18

-

19

-

19

-

20

-

20

-

21

-

21

Pressure side impect sensor [Passenger] Low

22

-

22

Pressure side impect sensor [Passenger] High

23

-

23

Curtain Airbag [Driver] High

24

-

24

Curtain Airbag [Driver] Low

25

-

25

Curtain Airbag [Passenger] Low

26

-

26

Curtain Airbag [Passenger] High

27

-

27

-

28

-

28

-

29

-

29

-

30

-

30

-

31

-

31

-

32

Local_CAN (IMU) Low

32

-

33

Local_CAN (IMU) High

33

-

34

Crash Output

34

Emergency fastening device [Driver] High

35

-

35

Emergency fastening device [Driver] Low

36

-

36

Emergency fastening device [Passenger] Low

37

-

37

Emergency fastening device [Passenger] High

38

-

38

Seat belt pretensioner [Driver] High

39

(1st stage) Driver airbag Low

39

Seat belt pretensioner [Driver] Low

40

(1st stage) Driver airbag High

40

Seat belt pretensioner [Passenger] Low

41

(1st stage) Passenger airbag High

41

Seat belt pretensioner [Passenger] High

42

(1st stage) Passenger airbag Low

42

-

43

C_CAN Low

43

Pressure side impect sensor Driver] Low

44

C_CAN High

44

Pressure side impect sensor [Driver] High
