Front pillar trim mounting hole (Ø12) | Front pillar trim mounting hole (Ø8.4) | Cowl crossbar mounting hole (Ø8.5) |
 |  |  |
Cowl side trim mounting hole (8.4X8.4) | Front door checker mounting hole (Ø13) | Seat belt height adjust upper mounting hole (Ø14) |
 |  | |
Seat belt height adjust lower mounting hole (Ø14) | Front seat belt retractor mounting hole (Ø12) |
| | |
Seat belt height adjust upper mounting hole (Ø14) | Seat belt height adjust lower mounting hole (Ø14) | Front seat belt retractor mounting hole (Ø12) |
 |  |  |
Rear door checker mounting hole (Ø13) | Rear pillar trim mounting hole (Ø8.5) | Quarter inner panel mounting hole (Ø16) |
 |  | |
Wheel house panel tooling hole (Ø12) | Rear door striker mounting hole (Ø13) |
| | |
Front pillar trim mounting hole (Ø12) | Front pillar trim mounting hole (Ø8.4) | Cowl crossbar mounting hole (Ø8.5) |
| | |
Cowl side trim mounting hole (8.4X8.4) | Seat belt height adjust upper mounting hole (Ø14) | Seat belt height adjust lower mounting hole (Ø14) |
|  | |
Front seat belt retractor mounting hole (Ø12) | Front seat mounting hole (Ø11) |
| | |
Seat belt height adjust upper mounting hole (Ø14) | Seat belt height adjust lower mounting hole (Ø14) | Front seat belt retractor mounting hole (Ø12) |
| | |
Rear pillar trim mounting hole (Ø8.5) | Quarter inner panel tooling hole (Ø16) | Wheel house panel tooling hole (Ø12) |
 | ||
Rear floor panel tooling hole (Ø15) |
