Fig.1) Operating Current of High Pressure Pump(Fuel Pressure Regulator) at Idle. The average operating current value is approximately 3A.

※ The value can be vary by few mA depends on the testing method and environement.

Fig.2) Operating Current of High Pressure Pump(Fuel Pressure Regulator) at Acceleration. The average operating current value is approximately 4,5A.

※ The value can be vary by few mA depends on the testing method and environement.
