Components
[M/T]

1. Floor console assembly

2. Console upper cover

3. Console side cover [LH]

4. Console side cover [RH]

5. Rear console cover

6. Floor console mounting bracket

[A/T]

1. Floor console assembly

2. Console upper cover

3. Console side cover [LH]

4. Console side cover [RH]

5. Rear console cover

6. Floor console mounting bracket
